Lumen Dynamics/EXFO S1500 S2000 Omnicure UV Spot Curing System
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Lamp: | High Pressure 200 Watt Mercury Vapor Short Arc | Lamp Life: | 2000 Hours (guaranteed) |
|---|---|---|---|
| Available Filters: | Standard: 320-500 Nm Optional: 250-450 Nm*, 365 Nm, 320-390 Nm, 400-500 Nm | Panel Controls: | Power On/Off, Display Mode, Adjust Up/Down, Start/Stop, Lock/Unlock |
| Power In: | 100-120 VAC / 200-240 VAC, 50/60 Hz | Power Supply: | High Efficiency, Switch Mode, Line Isolated |
| Dimensions (L X W X H): | 13.3” X 7.1” X 7.9” (33.8 Cm X 18.0 Cm X 20.1 Cm) | Weight: | 9.9 Lbs (4.5 Kg) |
OmniCure S2000 Spot UV Curing System
The OmniCure® S2000 Spot UV Curing System offers the highest level of process control and consistency with our proprietary, real-time Closed-Loop Feedback technology using an integrated optical UV sensor. When paired with an OmniCure R2000 radiometer, the S2000 UV curing system is unmatched in precision light delivery and repeatable, adhesive curing results.
|
OmniCure S2000 Spot UV Curing System |
|
| Lamp | High Pressure 200 Watt Mercury Vapor Short Arc |
| Lamp Life | 2000 hours (guaranteed) |
| Available Filters |
Standard: 320-500 nm Optional: 250-450 nm*, 365 nm, 320-390 nm, 400-500 nm |
| Panel Controls | Power On/Off, Display Mode, Adjust Up/Down, Start/Stop, Lock/Unlock |
| Panel Displays | Accumulated lamp usage, Exposure time (0.2 - 999.9 sec), iris setting (0-100%) / irradiance level (0.2 W/cm² - 40 W/cm²), lamp on/warm-up, shutter open, calibrated, Light Guide detection, shutter/lamp error |
| Warm-up Period | 4 minutes (typical) |
| Power In | 100-120 VAC / 200-240 VAC, 50/60 Hz |
| Power Supply | High efficiency, switch mode, line isolated |
| Dimensions (L x W x H) | 13.3” x 7.1” x 7.9” (33.8 cm x 18.0 cm x 20.1 cm) |
| Weight | 9.9 lbs (4.5 kg) |
